Name: Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Brand: BOJKE
Price: 95 USD

Features : Long-distance color recognition

MOQ : 1

Response Time : 200μm

Theory : Photoelectric Sensor

Manufacturer Part Number : BS-500NP

Voltage - Supply : DC12~24V ±10%

Place of Origin : Guangdong, China

Certification : CE

Payment Terms : T/T

Price : $95

Mounting Type : manual installation

Packaging Details : kraft paper box with carton box;

Model Number : BS-W50N

Brand Name : BOJKE

Type : Color Code Sensor

Description : color mark sensor, Color mark photoelectric sensor

Delivery Time : 5~8 work days

Supply Ability : 150k

Usage : Industrial Automation

Output : RS485

Contact Now

BOJKE RS485 Output 200μS Response Time Long-Distance Color Recognition Sensor Mark

Model	BS-W50N	BS-W50P
Output Type	NPN	PNP
Type	cable type
Conrol Output	1 output port, buit in short ciruit protection, and have automatic anti any interference function
Light Source	white LED ,adjustable spot ,minium spot diameter 3.6MM
Response Time	AUTO,C mode and CI mode 200us, at MARK mode 160us
Output Option	LIGHT-ON/DARK-ON
Indicator	Operation indicator light: red infrared, LED display screen
Detection Mode	AUTO,C mod, CI mod and MARK mode sensing distance: 30MM—500MM
Timer	OFF delay/ON delay/one-shot/ON one-shot timer optional,timer range(ms):1ms ~ 9999ms
Conrol Output	NPN open collector/PNP open collector 24V ,Maximum 100mA
	Max current consumption 40mA(when connect external, drop voltage:2V
Power Supply	12 ~ 24VDC±10%,ripple(P-P): ≤10％ class 2
Ambient Illuminace	Incandescent lamp: 20,000lux or less Sunlight:30,000lux or less
Consumption Power	Max Voltage:24V, Current within 60MA	Max Voltage: 24V,Current within 60MA
Vibration Resistance	10 ~ 55Hz ,double amplitude 1.5mm ,2 hours in each of the X,Y,Z directions
Ambient Temperature	- 10 ~ +55℃ , no freezing
