Name: Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor
Brand: BOJKE
Price: 36 USD

Place of Origin : Guangdong, China

Brand Name : BOJKE

MOQ : 1

Model Number : BS-201ZWN

Certification : CE

Price : $36

Payment Terms : T/T

Supply Ability : 150k

Delivery Time : 5~8 work days

Packaging Details : kraft box with carton box;

Product name : RGB Color Sensor

Usage : Color detection on production lines

Theory : Light Emission Reflection Detection RGB Filterin

Output : NPN/PNP

Response Time : <1ms

Voltage - Supply : DC12~24V ±10%

Contact Now

BOJKE Industrial High-Speed RGB Color Sensor IP66 Precise Detection Optical Sensor

Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor

Model No	BS-201ZWN	BS-201ZWP
Product Picture
Operation Voltage	DC 12~24V ±10%
Consumption (no-load) Current	≤35mA
Detection Range	17±5mm
Light Source	RGB color, LED
Detection Mode	color mode and color mark mode switchable
Response Time	< 1ms
Response Frequency	Color mode > 1000Hz； color mark mode > 1500Hz
Output Type	NPN open collector	PNP open collector
Max Input Current	<100mA
Residue Voltage	<1.5V
Switch Type	Light.on/Dark.on switchable
Ambient Illumination	Incandescent lamp ≤ 3000Lux; Sunlight ≤ 10000Lux
Ambient Temperature	operation:-10℃~55℃；storage:-25℃~75℃,no freezing
Ambient Humidity	operation: 35%~85% RH；storage:35%~95% RH no condensation
Protection Circuit	polarity reversal protection/surge protection/short circuit protection
Protection Level	IP67
Connection Type	4 core 2 meters standard cable
Housing Material	PC
Vibration Resistance	10～55Hz, dual amplitude 1.0mm, X/Y/Z directions each 30 minute
Impact Resistance	300m/S², X,Y,Z directions each 3 times
